Up to 16 units under test with each 32 test points can be managed by the LR- CalLPC 300 at a time.
#300 MBAR TO PSI SERIAL NUMBER#
One procedure has following data: Same like "Measuring Mode", plut Calibration Number (program no.), Serial number of unit unter test, location number of unit under test, test pressure points (up to 32 for each unit under test), dwell time (seconds) between test pressure points. In this mode, calibration procedures can be pre-defined, incl. The resolution adjustment (decimal point setting) can be made very comfortable.
#300 MBAR TO PSI PLUS#
With one view the operator sees wether the unit under test is within it's specification (accuracy class) or not - at every test point.ġ5 different pressure units are available for selection, plus an user-definable pressure unit.
#300 MBAR TO PSI FULL#
Then, the comparison calibration can be made: The display shows the pressure range of the LR- CalLPC-S reference sensor, the true pressure measured by the LR- CalLPC 300, the pressure range of the unit under test, the output signal of unit under test (measured if it is a transmitter, to be entered manually if it is an analogue pressure gauge), deviation in selected pressure unit of unit under test, deviation in percentage of full scale value of unit under test.
The electronic pressure calibrator (documenting process calibrator) LR- CalLPC 300 can be operated in three different modes:įirst, the operator defines the unit under test (analogue or digital, pressure range, accuracy class, pressure unit, gauge or absolute pressure, gaseous or fluid calibration medium, power supply 24 VDC on or off).
#300 MBAR TO PSI SOFTWARE#
ambient temperature, fluid level difference between reference and unit under test, Language (English/French/Italian/Spanish/German), Setting of the realtime clock, Setting of the display, Setting of the powersafe function, Indicating battery level, Tara value (offset), Indicating Min/Max values, Setting/indicating alarm values, Digital software filter, USB- and RS232 settings. Several basic parameters can be entered into the LR- CalLPC 300, e.g. The LR- CalLPC 300 features a complete numeric keypad and cursor block, for easy and simple entering of data. The reference pressure sensors LR- CalLPC-S are equipped with a welded stainless steel membrane, they are suitable for aggressive media, which do not destroy stainless steel 1.4571. Calibration certificate, traceable to national standard included in scope of standard delivery (for pressure, current and voltage).Power supply 24 VDC output for pressure transmitters.Menu-driven operating in several languags (English, Italian, French, Spanish, German).Stores calibration data (plus time stamp from integrated real time clock).Conversion pressure to volt/milliamps and vice versa.All standard pressure units (plus one self-definable).Changeable reference pressure sensors LR- CalLPC-S.Pressure ranges from 0.250 mbar to 0.4000 bar, as well as vacuum, compound and absolute ranges.Accurate, high resolution, compact, rigid.The LR- CalLPC 300 is featured with USB- and RS232-interfaces and is powered by a chargeable Lithium-Ion battery pack (no "memory effect").
Calibration procedures can be pre-defined and used for calibrations on site. The electronic pressure calibrator LR- CalLPC 300 measures pressure, volts and milliamps and supplies 24 VDC as source for transmitter. Furthermore, ranges up to 4000 bar are available with accuracy ☐.1% FS. The built-in reference sensor LR- CalLPC-S is changeable several pressure ranges can be covered with one LR- CalLPC 300 unit (up to 10).Īll standard pressure ranges between 0.250 mbar (0.4 psi) and 0.1000 bar (0.14500 psi) are available as well as vacuum and absolute pressure ranges in accuracy ☐.025% FS. The LR- CalLPC 300 is a very user-friendly, accurate and compact solution for pressure comparison calibrations. pressure gauges, pressure transmitter, digital manometer, pressure switches, overpressure protection valves, etc. The electronic pressure calibrator LR- CalLPC 300 is used for high precision calibration of pressure instruments, e.g. Electronic Pressure Calibrator Model LR- Cal LPC 300 Documenting Process Calibrator
